ilinxa/pro-ui

Carousel Composer

alphav0.5.0

Multi-item media post composer — drag in photos and videos, reorder them on a rail, alt text and upload status per item; image editing is an add-on.

Category: MediaUpdated: 2026-10-30Created: 2026-06-05Author: ilinxa

Context

The authoring counterpart to the media-carousel viewer. The base owns the collection concerns — file intake (drop + multiple browse, MIME-inferred, an optional exact MIME allow-list and video length limit), the ordered MediaCarouselItem model (controlled or uncontrolled), the @dnd-kit reorderable thumbnail rail, the main preview, per-image alt text, host-owned upload status / progress / retry, and a poster frame + duration for each video. A video item's output is always the original file — nothing in the folder re-encodes video. Image editing is NOT in the base: the feature item `carousel-composer-editing` (into `features/editing/`) supplies an edit panel built on media-editor and is passed in through the `editing` prop, so a plain install pulls no media-editor or Konva; a host can also inject its own panel. Edits flatten on apply, so the rail and preview are always publish-ready; export() is pull-only. Intake is upload-only (`"library"` is ignored). Output is shaped to feed media-carousel. Primary downstream consumer: content-composer's post media slot (mediaCarouselSlot substrate), which wires the editing add-on.

Installation

Initialize shadcn (once per project)Seeds lib/utils.ts and components.json. Skip if you've already used any shadcn component.
pnpm dlx shadcn@latest init
Install the component
pnpm dlx shadcn@latest add @ilinxa/carousel-composer

Add -fixtures for dummy data:

pnpm dlx shadcn@latest add @ilinxa/carousel-composer-fixtures
Optional feature slicesInstall on top of the base for opt-in heavier capability.
pnpm dlx shadcn@latest add @ilinxa/carousel-composer-editing

Image editing through media-editor — the edit panel, re-edit of earlier edits and typed readers for the edit fields, wired in through the editing prop.

CLI can't resolve @ilinxa? The namespace is listed in the official shadcn registry directory, so current CLIs need no configuration. If yours can't resolve it (older or pinned versions, self-hosted mirrors), register it manually in components.json:

"registries": {
  "@ilinxa": "https://ui.ilinxa.com/r/{name}.json"
}

Preview


Seeded from remote URLs (CMS re-edit). Select a thumb, drag to reorder, press Edit on any item. Videos can be previewed, reordered and removed, but not edited.

Demo source

demo.tsxtsx
"use client"; import * as React from "react";import { Tabs, TabsContent, TabsTrigger } from "@/components/ui/tabs";import { SwipeTabsList } from "@/components/site/swipe-tabs-list";import { Button, buttonVariants } from "@/components/ui/button";import {  Dialog,  DialogContent,  DialogDescription,  DialogTitle,  DialogTrigger,} from "@/components/ui/dialog";import { CarouselComposer } from "./carousel-composer";import type {  CarouselComposerHandle,  CarouselComposerLabelsInput,  MediaCarouselItem,} from "./types";import { PLATFORM_SAFE_MIME } from "./types";import { carouselEditing } from "./features/editing";import {  arabicLabels,  dummyCarouselItems,  dummyPanItems,  dummyStatusItems,  turkishLabels,} from "./dummy-data"; function Status({ children }: { children: React.ReactNode }) {  return (    <p className="mt-3 font-mono text-xs text-muted-foreground">{children}</p>  );} function EmptyTab() {  const [count, setCount] = React.useState(0);  return (    <div className="mx-auto max-w-md">      <CarouselComposer        onChange={(items) => setCount(items.length)}        editing={carouselEditing}        enableAltText        acceptMime={PLATFORM_SAFE_MIME}        maxVideoSeconds={30}        editorProps={{ enabledTools: ["crop", "filters", "adjust", "text"] }}      />      <Status>        Drop or browse photos + videos. {count} item{count === 1 ? "" : "s"}.      </Status>    </div>  );} function SeededTab() {  return (    <div className="mx-auto max-w-md">      <CarouselComposer        defaultValue={dummyCarouselItems}        editing={carouselEditing}        editorProps={{ enabledTools: ["crop", "filters", "adjust"] }}      />      <Status>        Seeded from remote URLs (CMS re-edit). Select a thumb, drag to reorder,        press Edit on any item. Videos can be previewed, reordered and removed, but not edited.      </Status>    </div>  );} function ControlledTab() {  const [items, setItems] = React.useState<MediaCarouselItem[]>([]);  const ref = React.useRef<CarouselComposerHandle>(null);  const [exported, setExported] = React.useState<number | null>(null);   return (    <div className="mx-auto max-w-md">      <CarouselComposer        ref={ref}        value={items}        onChange={setItems}      />      <div className="mt-3 flex flex-wrap gap-2">        <Button          size="sm"          onClick={async () => {            const out = await ref.current?.export();            setExported(out?.length ?? 0);          }}        >          Export (publish)        </Button>        <Button size="sm" variant="ghost" onClick={() => ref.current?.reset()}>          Reset        </Button>      </div>      <Status>        Controlled: {items.length} item{items.length === 1 ? "" : "s"} ·{" "}        {items.filter((i) => i.kind === "image").length} photo /{" "}        {items.filter((i) => i.kind === "video").length} video        {exported !== null ? ` · last export → ${exported} items` : ""}      </Status>    </div>  );} function MaxTab() {  const [warn, setWarn] = React.useState<string | null>(null);  return (    <div className="mx-auto max-w-md">      <CarouselComposer        maxItems={3}        defaultValue={dummyCarouselItems.slice(0, 2)}        onMaxItemsExceeded={(attempted, max) =>          setWarn(`Tried ${attempted}, cap is ${max}.`)        }      />      <Status>        Cap is 3. {warn ?? "Add more until the tile disappears."}      </Status>    </div>  );} function StatusTab() {  const [items, setItems] = React.useState<MediaCarouselItem[]>(dummyStatusItems);  const [retries, setRetries] = React.useState(0);  return (    <div className="mx-auto max-w-md">      <CarouselComposer        value={items}        onChange={setItems}        onRetry={(item) => {          setRetries((n) => n + 1);          setItems((cur) =>            cur.map((it) =>              it.id === item.id                ? { ...it, status: "uploading", progress: 0.1, error: undefined }                : it,            ),          );        }}      />      <Status>        Host-owned upload state: item 1 is uploading at 40 %, item 2 failed.        Select item 2 and press Retry ({retries} retries).      </Status>    </div>  );} function AltVideoTab() {  return (    <div className="mx-auto max-w-md">      <CarouselComposer defaultValue={dummyCarouselItems} enableAltText="all" />      <Status>        enableAltText=&quot;all&quot;: select the video (item 3) and describe it; the preview video is named by that text.      </Status>    </div>  );} function PanTab() {  const ref = React.useRef<CarouselComposerHandle>(null);  const [log, setLog] = React.useState("—");  const [crops, setCrops] = React.useState<string[]>([]);  return (    <div className="mx-auto max-w-md">      <CarouselComposer        ref={ref}        defaultValue={dummyPanItems}        defaultAspect="1:1"        aspectOptions={["1:1", "4:5", "1.91:1"]}        enablePan        editing={carouselEditing}        editorProps={{ enabledTools: ["crop", "filters", "adjust"] }}        onCropOffsetChange={(id, o) => setLog(`${id} → ${o.x.toFixed(2)}, ${o.y.toFixed(2)}`)}      />      <div className="mt-3">        <Button          size="sm"          onClick={async () => {            const out = (await ref.current?.export()) ?? [];            setCrops(              out.map((it, i) =>                it.crop ? `#${i + 1} ${it.crop.width}x${it.crop.height} @${it.crop.x},${it.crop.y}` : `#${i + 1} no crop`,              ),            );          }}        >          Export        </Button>      </div>      <Status>        Drag the wide or tall photo inside the frame, or focus it and use the arrow keys (Shift = 20 %). The rail        thumb follows. Pan, then Edit and Done: the framing survives the edit and the offset clears. onCropOffsetChange: {log}        {crops.length ? ` · ${crops.join(" · ")}` : ""}      </Status>    </div>  );} function ReorderTab() {  const ref = React.useRef<CarouselComposerHandle>(null);  const [log, setLog] = React.useState("—");  // The narrowest thumb (9:16) and a native RTL mount; the rail reads direction at mount, so  // either switch remounts the composer.  const [narrow, setNarrow] = React.useState(false);  const [rtl, setRtl] = React.useState(false);  return (    <div className="mx-auto max-w-md" dir={rtl ? "rtl" : undefined}>      <CarouselComposer        key={`${narrow}-${rtl}`}        ref={ref}        defaultValue={dummyCarouselItems}        defaultAspect={narrow ? "9:16" : undefined}        aspectOptions={narrow ? ["9:16"] : undefined}        reorderButtons        onMove={(id, d) => setLog(`${id} ${d > 0 ? "+" : ""}${d}`)}      />      <div className="mt-3 flex flex-wrap gap-2">        <Button size="sm" onClick={() => ref.current?.moveItem("seed-1", 1)}>          handle.moveItem(seed-1, +1)        </Button>        <Button size="sm" variant="outline" aria-pressed={narrow} onClick={() => setNarrow((v) => !v)}>          Shared aspect 9:16        </Button>        <Button size="sm" variant="outline" aria-pressed={rtl} onClick={() => setRtl((v) => !v)}>          Mount under dir=rtl        </Button>      </div>      <Status>        Tab to a thumb: a move earlier / later pair appears on focus (logical direction, works in RTL). onMove: {log}      </Status>    </div>  );} function EscapeTab() {  const [open, setOpen] = React.useState(false);  const [editing, setEditing] = React.useState(false);  return (    <div className="mx-auto max-w-md">      <Dialog open={open} onOpenChange={setOpen}>        {/* A real trigger: closing returns focus to it instead of <body>. */}        <DialogTrigger className={buttonVariants({ size: "sm" })}>          Open carousel in a dialog        </DialogTrigger>        <DialogContent className="max-w-lg">          <DialogTitle>Post media</DialogTitle>          <DialogDescription>Add, reorder and edit the media for this post.</DialogDescription>          <CarouselComposer            defaultValue={dummyCarouselItems.slice(0, 2)}            editing={carouselEditing}            onEditingChange={setEditing}            editorProps={{ enabledTools: ["crop", "filters", "adjust"] }}          />        </DialogContent>      </Dialog>      <Status>        Press Edit, then Escape while the editor loads or Done is exporting: the dialog stays open. When idle,        Escape closes it as before. Editing now: {String(editing)}.      </Status>    </div>  );} function LocaleTab({  dir,  locale,  labels,  note,}: {  dir: "ltr" | "rtl";  locale: string;  labels: CarouselComposerLabelsInput;  note: string;}) {  return (    <div className="mx-auto max-w-md" dir={dir} lang={locale}>      <CarouselComposer        defaultValue={dummyCarouselItems.map((it) =>          it.kind === "video" ? { ...it, duration: 75 } : it,        )}        locale={locale}        labels={labels}        enableAltText      />      <Status>{note}</Status>    </div>  );} function AspectTab() {  const ref = React.useRef<CarouselComposerHandle>(null);  const [log, setLog] = React.useState<string[]>([]);  const [crops, setCrops] = React.useState<string[]>([]);  return (    <div className="mx-auto max-w-md">      <CarouselComposer        ref={ref}        defaultValue={dummyCarouselItems}        editing={carouselEditing}        defaultAspect="original"        aspectOptions={["original", "1:1", "4:5", "1.91:1"]}        onAspectChange={(a) => setLog((l) => [...l.slice(-2), a])}        editorProps={{ enabledTools: ["crop", "filters", "adjust"] }}      />      <div className="mt-3 flex flex-wrap gap-2">        <Button          size="sm"          onClick={async () => {            const out = (await ref.current?.export()) ?? [];            setCrops(              out.map((it, i) =>                it.crop                  ? `#${i + 1} ${it.crop.width}x${it.crop.height} @${it.crop.x},${it.crop.y}`                  : `#${i + 1} no crop`,              ),            );          }}        >          Export        </Button>      </div>      <Status>        Select item 1 to switch the shared aspect; every thumb, the preview and the editor follow.        onAspectChange: {log.length ? log.join(" → ") : "—"}        {crops.length ? ` · ${crops.join(" · ")}` : ""}      </Status>    </div>  );} export default function CarouselComposerDemo() {  const [tab, setTab] = React.useState("seeded");  return (    <Tabs value={tab} onValueChange={setTab} className="w-full">      <SwipeTabsList>        <TabsTrigger value="empty">Empty</TabsTrigger>        <TabsTrigger value="seeded">Seeded (re-edit)</TabsTrigger>        <TabsTrigger value="controlled">Controlled + export</TabsTrigger>        <TabsTrigger value="max">Max 3</TabsTrigger>        <TabsTrigger value="aspect">Aspect switch</TabsTrigger>        <TabsTrigger value="status">Upload status</TabsTrigger>        <TabsTrigger value="alt-video">Alt for videos</TabsTrigger>        <TabsTrigger value="pan">Pan</TabsTrigger>        <TabsTrigger value="reorder">Reorder buttons</TabsTrigger>        <TabsTrigger value="escape">Escape guard</TabsTrigger>        <TabsTrigger value="tr">Türkçe</TabsTrigger>        <TabsTrigger value="ar">العربية (RTL)</TabsTrigger>      </SwipeTabsList>       <TabsContent value="empty" className="pt-4">        <EmptyTab />      </TabsContent>      <TabsContent value="seeded" className="pt-4">        <SeededTab />      </TabsContent>      <TabsContent value="controlled" className="pt-4">        <ControlledTab />      </TabsContent>      <TabsContent value="max" className="pt-4">        <MaxTab />      </TabsContent>      <TabsContent value="aspect" className="pt-4">        <AspectTab />      </TabsContent>      <TabsContent value="status" className="pt-4">        <StatusTab />      </TabsContent>      <TabsContent value="alt-video" className="pt-4">        <AltVideoTab />      </TabsContent>      <TabsContent value="pan" className="pt-4">        <PanTab />      </TabsContent>      <TabsContent value="reorder" className="pt-4">        <ReorderTab />      </TabsContent>      <TabsContent value="escape" className="pt-4">        <EscapeTab />      </TabsContent>      <TabsContent value="tr" className="pt-4">        <LocaleTab dir="ltr" locale="tr" labels={turkishLabels} note="Turkish labels and tr-locale formatting. Turkish writes digits the same way as English, so the video length still reads 1:15." />      </TabsContent>      <TabsContent value="ar" className="pt-4">        <LocaleTab dir="rtl" locale="ar-EG" labels={arabicLabels} note="Arabic labels, right-to-left rail, Arabic-Indic digits." />      </TabsContent>    </Tabs>  );}

Usage

When to use

Reach for CarouselComposer when an author needs to assemble one or more media items into an ordered set — an Instagram-style feed post, an album, a product gallery, or chat attachments. It mixes photos and videos in a single rail, reorders by drag-and-drop, and can edit images through the optional editing add-on. For a single hero image/video, use media-editor directly; to display a finished set, use media-carousel.

Basic example

import { CarouselComposer, PLATFORM_SAFE_MIME, type MediaCarouselItem } from "@/components/carousel-composer";

export function PostMedia() {
  const [items, setItems] = React.useState<MediaCarouselItem[]>([]);
  return (
    <CarouselComposer
      value={items}
      onChange={setItems}
      maxItems={10}
      acceptMime={PLATFORM_SAFE_MIME} // no WebM
      maxVideoSeconds={60}
      enableAltText
    />
  );
}

Image editing (add-on)

Editing is a separate registry item, so a plain install pulls no media-editor or Konva. Install @ilinxa/carousel-composer-editing and pass it in; without it there is no Edit button. canEditItem decides per item (videos are never edited — their output is the original file).

import { carouselEditing, type CarouselEditorProps } from "@/components/carousel-composer/features/editing";

const editorProps: CarouselEditorProps = { enabledTools: ["crop", "filters", "adjust"] };

<CarouselComposer
  value={items}
  onChange={setItems}
  editing={carouselEditing}
  editorProps={editorProps}
  canEditItem={(item) => item.status !== "uploading"}
/>

One shared aspect, any ratio

Every item shares the carousel's aspect — the preview, the rail thumbs, the edit panel and an edit's export follow it. aspectOptions shows a switch while item 1 is selected; enablePan lets the author drag a photo inside the frame (its cropOffset); export() gives each image the crop for the aspect — centred unless panned — so every item can be uploaded at it.

<CarouselComposer
  value={items}
  onChange={setItems}
  aspect={aspect}                 // "original" | "1:1" | "4:5" | "1.91:1" | any "W:H" | "auto" | "free"
  onAspectChange={setAspect}
  aspectOptions={["original", "1:1", "4:5", "1.91:1"]}
  enablePan                       // drag / arrow keys move the item's cropOffset
  enableAltText="all"             // videos get a description too
  reorderButtons                  // move earlier / later, shown on hover or focus
  onEditingChange={setEditing}    // keep your dialog open while editing
  editing={carouselEditing}
/>

const items = await ref.current.export(); // each image: crop = { x, y, width, height }
ref.current.moveItem(id, 1);              // the same move without UI

Upload status

Upload on add and write the state onto the item — the carousel shows a progress indicator, the error with a Retry, and announces each status change politely. Controlled hosts set it in value; uncontrolled hosts call ref.current.updateItem(id, patch).

const patch = (id, p) => setItems((prev) => prev.map((it) => (it.id === id ? { ...it, ...p } : it)));

async function upload(item) {
  patch(item.id, { status: "uploading", progress: 0, error: undefined });
  try {
    const { url } = await api.upload(item.blob, { onProgress: (progress) => patch(item.id, { progress }) });
    patch(item.id, { status: "uploaded", url });
  } catch (e) {
    patch(item.id, { status: "error", error: e.message });
  }
}

<CarouselComposer value={items} onChange={setItems} onItemAdd={upload} onRetry={upload} />

Labels and locale

Every string is in labels; strings that carry a value are functions. errors and drag merge key by key.

<CarouselComposer
  locale="tr"
  labels={{
    dropzoneTitle: "Fotoğraf ve videoları buraya sürükleyin",
    dropzoneHint: (max) => `veya en fazla ${max} dosya bırakın`,
    maxReached: (max) => `En fazla ${max} öğe eklenebilir`,
    itemAria: ({ position, total, kind }) => `${total} öğeden ${position}., ${kind === "video" ? "video" : "fotoğraf"}`,
    errors: { videoTooLong: ({ maxSeconds }) => `Video en fazla ${maxSeconds} sn olabilir.` },
  }}
/>

Pull-only export

Edits flatten into each item on Done, so the rail and preview always show publish-ready media. Call ref.current.export() at publish time to get the committed ordered array (an open, unapplied edit is excluded — gate your publish button while editing).

Notes

  • Intake is file-based — the file's MIME type decides image vs video, so there are no photo/video capture tabs. "library" in sources is ignored.
  • All items share one aspect (Instagram behaviour). aspect defaults to "auto" (derived from item 1); override with a fixed CarouselAspectRatio.
  • A video gets a JPEG poster frame (posterAt, default 0.5 s; false for none) and a duration badge; the video itself is never re-encoded.
  • Object URLs created during intake / edit (items and posters) are revoked on remove, replace, reset, and unmount.

Features

  • Multi-file intake — drag-and-drop dropzone + multiple Browse, mixed image + video (MIME-inferred, no capture-mode tabs)
  • Type checks — `accept` kinds plus an exact `acceptMime` allow-list (also the file input's accept); `PLATFORM_SAFE_MIME` refuses WebM; `maxVideoSeconds` from the file's duration
  • Ordered MediaCarouselItem model — add / remove / reorder / select; controlled `value` wins every render
  • Reorderable thumbnail rail (@dnd-kit horizontal sortable) with pointer + keyboard reorder, a dedicated drag handle and labelled drag announcements
  • Main preview of the selected item (image cover-fit; video on a media-overlay mat)
  • Alt text (`enableAltText`, `maxAltLength`) — images by default; `"all"` or a per-item function describes videos too (the preview video is named by it); carried on the item through onChange
  • Pan inside the shared frame (`enablePan`) — drag or arrow keys move an image's `cropOffset`; preview, rail thumb and `export()`'s `crop` follow it (`onCropOffsetChange`)
  • Non-drag reorder (`reorderButtons`) — a move earlier / later pair per thumb (shown on thumb hover or when focused, logical in RTL, announced), `onMove`, handle `moveItem`
  • Escape guard — while an edit panel reports busy (`onBusyChange`; the add-on reports its load and save) Escape never reaches a host dialog; `onEditingChange` lets a host gate its own dialog
  • Host-owned upload status — `status` / `progress` / `error` on the item, a progress indicator on thumb and preview, Retry via `onRetry`, polite announcements on status changes, handle `updateItem`
  • Video poster frame (JPEG `posterBlob` at `posterAt`) and a duration badge (`formatDuration` / `locale`); the video itself is never re-encoded
  • Image editing as an opt-in add-on (`editing` prop, `@ilinxa/carousel-composer-editing`) — no Edit button and no media-editor in the install without it; `canEditItem` decides per item
  • Shared aspect across the carousel (Instagram behaviour) — any media-editor crop aspect (named, `"original"` = item 1's ratio, `"W:H"` such as `"1.91:1"`); `"auto"` snaps item 1 to the nearest option; controlled (`aspect` + `onAspectChange`) or `defaultAspect`; an `aspectOptions` switch on item 1; preview, rail thumbs and the edit panel follow it, an edit exports at it, and `export()` reports each image's centred `crop`
  • Imperative handle — getItems / export / addFiles / removeItem / moveItem / updateItem / select / openEditor / reset; pull-only export()
  • Every string in `labels` (functions where a value varies); media-overlay tokens; logical (RTL-safe) layout
  • Per-file type + size validation; maxItems cap (default 10, Instagram parity)
  • Object-URL lifecycle managed (items and posters revoked on remove / replace / reset / unmount)

Tags

carousel-composercarouselgallerymediauploadereditordrag-and-dropinstagram

Dependencies

shadcn primitives: button, input, scroll-area
npm peer deps: @dnd-kit/core@^6.3.1, @dnd-kit/sortable@^10.0.0, @dnd-kit/utilities@^3.2.2, lucide-react@^1.11.0
internal: media-editor
